Mixing Tanks | Reactor Vessels | Pressure Vessels | Agitators | Internal Linings
Process Vessel Repair and Linings
ASTM-tested coatings that outperform industrial standards — applied cold, in place, with local expertise you can trust.
When Standard Coatings Fall Short
Process vessels face some of the harshest conditions in any industrial facility — aggressive chemicals, elevated temperatures, abrasive slurries, and constant thermal cycling. Standard industrial coatings are designed for general corrosion protection, not the specialized demands of chemical processing, pulp and paper, food and beverage, or power generation environments.
Belzona process vessel solutions are engineered for performance and tested to prove it. While many coatings claim chemical resistance, Belzona products are tested to ASTM standards across hundreds of chemical combinations, temperatures, and exposure durations — and we publish the results.
Cold-applied and in-situ curing means no hot work permits, no vessel removal, and faster return to service. And with over 100 years of combined experience in the Pacific Northwest — including NACE Level 1-3 and SSPC certified professionals who have worked these industries for decades — you get local expertise that understands your facility, your regulations, and your operational constraints.
Pacific Northwest Expertise Since Day One
Our team brings over 100 years of combined experience — all of it in Washington, Oregon, Alaska, and Northern Idaho. We hold NACE Level 1-3 certifications and SSPC credentials, but more importantly, we've spent decades working inside the refineries, pulp mills, power plants, and processing facilities of the Pacific Northwest. We know what works in your environment, we understand your regulatory landscape, and we're here when you need us — not across the country waiting for a flight.
Tested Performance, Not Marketing Claims
Most industrial coatings publish basic adhesion and hardness. Belzona publishes complete ASTM test results across dozens of performance categories — so you can verify before you specify.
4,800
PSI Pull-Off Adhesion
ASTM D4541
7,630
PSI Flexural Strength
ASTM D790
6,900
PSI Compressive Strength
ASTM D695
87
Shore D Hardness
ASTM D2240
What Belzona Publishes
- Adhesion values on 5 different substrates (aluminum, brass, copper, mild steel, stainless)
- 6-month seawater immersion at 122°F — no blistering, rusting, cracking, or delamination
- Chemical resistance across 100+ chemicals with temperature and duration data
- Cathodic disbondment testing (ASTM G8) — 0.35 in. ECD
- Flexibility testing at 0°F — no cracks, tears, or disbonding (NACE SP0394)
- ABS Product Type Approval for marine applications
What Most Coatings Publish
- "Excellent adhesion" with no PSI values
- "Resistant to water immersion" — no duration or temperature specified
- "Chemical resistant" — 10-20 chemicals listed, often at room temp only
- No cathodic protection compatibility data
- No cold-temperature flexibility testing
- No third-party certifications or class approvals
Performance data shown from Belzona 5811 Immersion Grade specification sheet. Each Belzona product has equally comprehensive testing documentation.
Products for Every Vessel Challenge
Metal Repair and Rebuilding
Super Metal
Two-part epoxy paste for rebuilding corroded and eroded metal surfaces. Service temperature up to 80°C (176°F) dry, 60°C (140°F) wet. The workhorse for general vessel repair.
View SpecificationsCeramic R-Metal
Ceramic-reinforced epoxy for erosion and corrosion resistance. Outstanding abrasion resistance for slurry handling, cyclones, and high-wear areas. ASTM G65 tested.
View SpecificationsChemical Immersion Protection
Ceramic S-Metal
Solvent-free ceramic epoxy for chemical immersion up to 60°C (140°F). Resists acids, alkalis, solvents, and hydrocarbons. ASTM D543 tested across 100+ chemicals.
View SpecificationsCeramic HT
High-temperature chemical immersion up to 120°C (248°F), with steaming-out capability to 210°C (410°F). For reactor vessels and hot chemical processing.
View SpecificationsHigh Temperature and Specialty
HTS
High-temperature metal repair up to 160°C (320°F) continuous service. For heat exchangers, high-temp vessels, and equipment that cannot be cooled for repair.
View SpecificationsSupermetalglide
Low-friction coating for sliding and rotating surfaces. Protects agitator shafts, bearing housings, and sealing surfaces. Excellent release properties.
View SpecificationsPerformance Comparison
| Capability | Belzona | Standard Industrial | Rubber Linings |
|---|---|---|---|
| ASTM chemical testing | 100+ chemicals | 10-20 chemicals | Limited |
| Abrasion testing (ASTM G65) | Published data | Rarely tested | Good |
| Cold application | Yes — no hot work | Some | Requires vulcanizing |
| In-situ repair | Yes | Yes | Requires removal |
| High-temp immersion | Up to 120°C | 60°C typical | 80°C typical |
| Metal rebuilding | Yes — structural | Coating only | No |
| Local technical support | NACE/SSPC certified, PNW-based | National hotline | Varies |
Applications
Mixing Tanks
Protect against chemical attack, rebuild eroded walls, and line tanks for long-term corrosion resistance. Products selected based on your specific chemical environment.
Reactor Vessels
High-temperature chemical immersion protection for reactors handling aggressive chemistry. Belzona 1391T provides continuous service up to 120°C with steaming-out capability.
Pressure Vessels
Rebuild corroded shell sections, repair nozzle connections, and protect internal surfaces — all without hot work permits or vessel removal from service.
Agitator Shafts
Rebuild worn shafts to original dimensions, protect sealing surfaces, and apply low-friction coatings for reduced wear. Belzona 1341 provides excellent release properties.
Manways and Nozzles
Repair and protect high-wear entry points, rebuild corroded flanges, and seal leaking connections without welding or hot work.
Baffles and Internals
Protect internal components from erosion and chemical attack. Ceramic-reinforced systems provide outstanding abrasion resistance in slurry and high-flow environments.
Industries We Serve
Frequently Asked Questions
How do I know which Belzona product to use?
Product selection depends on your chemical environment, operating temperature, and type of damage. Contact us with your specific conditions — we'll review Belzona's chemical resistance data and recommend the right system.
Can you repair vessels without removing them from service?
Yes. Belzona products are cold-applied and cure at ambient temperature. Most repairs can be completed during scheduled maintenance windows without removing equipment or requiring hot work permits.
What surface preparation is required?
Proper surface preparation is critical. Depending on the product, this typically involves solvent degreasing, abrasive blasting or mechanical preparation to white metal or near-white metal, and application of Belzona conditioner. We provide detailed specs and on-site support.
How long do repairs last?
With proper surface preparation and product selection, Belzona repairs routinely last 10-20+ years. We have documented case studies throughout the Pacific Northwest with repairs still performing after decades of service.
Are Belzona products FDA compliant?
Several Belzona products are FDA compliant for incidental food contact. For food and beverage applications, contact us to discuss your specific requirements and we'll recommend compliant solutions.
Do you provide on-site application support?
Yes. Our NACE-certified team provides training, application guidance, and on-site supervision throughout Washington, Oregon, Alaska, and Northern Idaho. We've worked in facilities across the region and understand local requirements.
How quickly can I get product?
We stock common products locally and can typically ship within 24-48 hours for standard orders. For emergency repairs, same-day delivery may be available depending on location. Call us directly for urgent needs.
Where can I find chemical resistance data?
Belzona publishes comprehensive chemical resistance charts for each product on their website. We can also provide specific immersion test results for your chemicals and help interpret the data for your application.
Process Vessel Challenge?
Describe your vessel, chemical environment, and operating conditions. Our NACE-certified team will review Belzona's ASTM test data and recommend the right solution — backed by decades of Pacific Northwest experience.
Belzona Technology Northwest is the exclusive authorized Belzona distributor for Washington, Oregon, Alaska, and Northern Idaho. Process vessel repair, tank linings, and ASTM-tested chemical protection — with NACE and SSPC certified local expertise throughout the Pacific Northwest.
